Commercial Kitchen Extraction Hood 2400mm Kit
Description
Commercial kitchen extraction extractor hood with powerful external extractor fan for fast and efficient kitchen extraction. The kitchen extraction canopy is suitable for both gas and electric cooking equipment. The kitchen fan hood comes with easy clean removable kitchen grease baffle filters and full length grease channel for easy cleaning.
The kitchen fan can discharge from the rear or the top as your require. We have a number of configurations from you to choose from, please select when ordering.
Materials
The extraction hood is 100% commercial stainless steel construction. The stainless steel has an elegant brushed finish and looks clean bright and modern.
The construction has formed stainless steel safety edges formed into all edges for safe and easy cleaning.
The hood has an integrated condense grease channel around the perimeter as per the requirements of DW/172. Taking this a step further we have a full length collector channel at the rear of the canopy to further aid in easy cleaning.
The extractor fan motor is a high quality twin inlet centrifugal design with high volume and high pressure extract fan with high quality ball bearing construction than runs at a low 65dB(A)
The extract fan motor has variable speeds that are easily selected from our rugged electronic speed controller. It is very suitable for commercial cooking applications in a commercial setting such as cafes, sandwich shops and coffee shops.
Extraction Canopy Hood Kit Contents
1off Stainless steel extraction canopy
2off side infil panels
2off Baffle filters
1off Externally mounted extractor fan motor.
1off Extractor fan with Variable Speed Controller
1off 350mm diameter ductwork with an extra coupler
1off Wall Termination cowl
Duct Fixing pack
Features
Easy to install
Electronic Variable speed controller
Quiet and powerful fan
Commercial kitchen hood for Gas and electric equipment
Commercial kitchen ventilation regulations compliant
Good for commercial canopy grills, cafes, coffee shops
Canopy Fan Hood Dimensions
2400mm (Width) x 1100mm (Depth)
500mm (Back Height) & 250mm (Front Height)
Fan diameter: 355mm Model: Commercial Kitchen Extraction Hood 2400mm Kit
