Rectangular chambered front-loading autoclaves with powered vertical sliding doors are often the best solution when floor-space is at a premium but large-volume/high-throughput operation is a must. Each of our front-loading autoclaves is entirely custom built to your specifications in our London factory. If you don’t need a steam jacket or exhaust filtration, then your autoclave won’t have it. If you do need enhanced cooling, monitoring, or another feature, it will be fitted. Far from being an extravagant luxury, a built-to-order autoclave is usually a money saver: Eliminating unneeded features doesn’t just reduce the purchase price; it also results in a more reliable autoclave that costs much less to own, operate, and maintain.
GBP £10,000 – 15,000
Product Description
Priorclave rectangular autoclaves are noted for their reliability, affordability, and ease-of-use. Our power door rectangular autoclaves couple the superior engineering and craftsmanship found in our standard research autoclaves with larger chambers. These units are optimised for high-throughput and large volume applications in facilities with little room to spare.
Power door rectangular models can be configured for in-chamber on-demand heating, integral steam generator, or house steam. They include our programmable Tactrol control system–celebrated for its robust construction and highly flexible programming–as standard. The result is a reliable rectangular autoclave that you can own, operate, and maintain at a significant savings, when compared to same-size, same-function units. Popular with colleges and universities, large research facilities, testing labs, and industrial applications.
Models
Model: EH230PD-BASE
Model: SH230PD-BASE
Model: EH230PD-SMART
Model: SH230PD-SMART
Model: EH230PD-PERFORMANCE
Model: SH230PD-PERFORMANCE
Model: EH350PD-BASE
Model: SH350PD-BASE
Model: EH350PD-SMART
Model: SH350PD-SMART
Model: EH350PD-PERFORMANCE
Model: SH350PD-PERFORMANC
Model: EH450PD-BASE
Model: SH450PD-BASE
Model: EH450PD-SMART
Model: SH450PD-SMART
Model: EH450PD-PERFORMANCE
Model: SH450PD-PERFORMANCE
Model: EH700PD-BASE
Model: SH700PD-BASE
Model: EH700PD-SMART
Model: SH700PD-SMART
Model: EH700PD-PERFORMANCE
Model: SH700PD-PERFORMANCE
Standard Features
Programmable TACTROL® 3 Control System with simple “one-touch” start
Customisable Freesteaming, Load Cooling, Media Warming, and Delayed Start
PED-certified 316L Stainless Steel Chamber and Hydraulically Operated Door
Two full width stainless steel anti-tip Loading Shelves
Biomaster™ Antimicrobial Surfaces
USB Port
Air Intake Filter System
Auto-waterfill
Calibration
Cycle Repeat
Double Door Override
Air Ballast System
Exhaust Filtration
Accelerated Media Cooling
Adaptation for special water supplies.
Additional Options Kit for Health Service Customers
Air Ballasting with built-in air compressor
Condensate Collection Bottle
Customer requested Pressure Vessel Approval
F0 Integration
Factory Acceptance Test
Fascia Panelling in Stainless Steel for Rectangular Priorclaves
Graphic Recorder Ethernet Port
Heater Protection
Installation – UK Mainland
IQ/OQ/PQ Documentation
Load Sensed Process Timing
Manual Drain
Mechanical Cycle Counter
Operator Identification
Performance Testing
Pneumatic Valves
Recorder – Circular Chart
Recorder – Graphic – Logger
Recorder – Strip Chart
Serial Communications Package
Setting Lock
Steam / Electric Heating
Steam Supply Set
TACTROL Self – Monitoring System
Touch Screen Option
Water Softener
Wire Basket Front Loading Models
Specifications
230L Power Door Specifications
Working Volume
230 litres
Chamber Size
580 x 600 x 600mm
Chamber Material
Burnished 316 Stainless Steel
Loading Format
Front
Loading Height
950mm
Operating Range
up to 138°C, 2.4 bar
Heater Power
21kW 30A three-phase
External Dimensions
(w x d x h)
905 x 1510 x 1880mm
Minimum Installation
Depth x Width
2000 x 905mm
Weight
960kg
350L Power Door Specifications
Working Volume
350 litres
Chamber Size
580 x 900 x 600mm
Chamber Material
Burnished 316 Stainless Steel
Loading Format
Front
Loading Height
950mm
Operating Range
up to 138°C, 2.4 bar
Heater Power
21kW 30A three-phase
Weight
1060kg
External Dimensions
(w x d x h)
905 x 1510 x 1880mm
Minimum Installation
Depth x Width
2000 x 905mm
450L Power Door Specifications
Working Volume
450 litres
Chamber Size
675 x 900 x 755mm
Chamber Material
Burnished 316 stainless steel
Loading Format
Front
Loading Height
1080mm
Operating Range
up to 138°C, 2.4 bar
Heater Power
32.5kW 45A three-phase
Weight
1180kg
External Dimensions
(w x d x h)
1540 x 1525 x 2065mm
Minimum Installation
Depth x Width
2050 x 1540mm
700L Power Door Specifications
Working Volume
700 litres
Chamber Size
675 x 1360 x 755mm
Chamber Material
Burnished 316 stainless steel
Loading Format
Front
Loading Height
1080mm
Operating Range
up to 138°C, 2.4 bar
Heater Power
42kW 60A three-phase
Weight
1360kg
External Dimensions
(w x d x h)
1540 x 1975 x 2065mm
Minimum Installation
Depth x Width
2500 x 1540mm
