You can be small of stature without being a pip-squeak or pushover. Priorclave’s benchtop autoclaves pack the performance and quality construction of a full-size, freestanding industrial autoclave into a footprint that fits any workspace. A quality research-grade benchtop autoclave offers all the flexibility, ease-of-use, and reliability that a small lab needs. Our compact tabletop units offer plug-n-play simplicity but come with fully featured programmable control systems. They are perfect for media prep, liquid, and waste loads. A great fit for shared facilities and education.
GBP £8,000 – 13,000
Product Description
All too often labs shopping for benchtop research-grade autoclaves end up being sold either a glorified pressure cooker or a low-end tabletop medical steriliser. The former lack the programmable controls a lab needs (in fact, they often lack even the rudimentary controls of a toaster oven). The latter are made with lightweight plumbing, pressure vessels, and electrical systems that aren’t up to research tasks. Since they were originally intended for dental offices and other clinics, their control systems are often limited to a few pre-programmed, medical type cycles. “Low-cost” dental-style benchtop autoclaves used for daily research tasks often begin to break down in just 24 months, and rarely last longer than five years.
Premium Benchtop Sterilizers
For more than 25 years Priorclave has been building some of the world’s finest research-grade sterilisers. Our 40L Benchtop and 60L Benchtop compact research-grade autoclaves feature fully customisable digital control systems.
Models
Model: B40-BASE
Model: B40-SMART
Model: B60-BASE
Model: B60-SMART
Standard Features
Programmable Tactrol® 3 Control System with simple “one-touch” start
PED-certified 316L Stainless Steel Chamber and Door
Quickseal Single-Action Interlocking Safety Door—cannot be opened unsafely
Two Full width stainless steel anti-tip Loading Shelves
Biomaster™ Antimicrobial Surfaces
Assisted Load Cooling
Chamber Pressure Gauge
Benchtop or Mobile Cart mounted for ease of positioning and service
One-button start
Permission-based Door Release
Automatic Timed Freesteaming
Media Warming and Delayed Start
Thermocouple Entry and Test Ports
Auto-waterfill
Calibration
Cycle Repeat
Air Ballast System
Accelerated Media Cooling
Adaptation for special water supplies.
Additional Options Kit for Health Service Customers
Air Ballasting with built-in air compressor
Condensate Collection Bottle
Customer requested Pressure Vessel Approval
F0 Integration
Factory Acceptance Test
Graphic Recorder Ethernet Port
Heater Protection
Installation – UK Mainland
IQ/OQ/PQ Documentation
Load Sensed Process Timing
Manual Drain
Mechanical Cycle Counter
Operator Identification
Performance Testing
Pneumatic Valves
Recorder – Circular Chart
Recorder – Graphic – Logger
Recorder – Strip Chart
Serial Communications Package
Setting Lock
Single Phase Connection
Steam / Electric Heating
Steam Supply Set
TACTROL Self – Monitoring System
Touch Screen Option
Water Softener
Specifications
40L Benchtop Specifications
Working Volume
40 litres
Operating Range
up to 138°C, 2.4 bar
Loading Format
Front Loading
Loading Height
N/A
Heater Power
3kW – 13A single phase
Heat Input
Heaters in Chamber
Chamber Size
diameter x depth
350mm dia x 420mm
External Dimensions
w x d x h
520 x 610 x 640mm
Bench Weight
70kg
Minimum Installation
w x d x h (and Door Swing)
826 x 762 x 793mm (520mm)
40L Benchtop Vacuum Specifications
Working Volume
40 litres
Operating Range
up to 138°C, 2.4 bar
Loading Format
Front Loading
Loading Height
N/A
Heater Power
3kW – 13A single phase
Heat Input
Heaters in Chamber
Chamber Size
diameter x depth
350mm dia x 420mm
External Dimensions
w x d x h
695 x 610 x 640mm
Bench Weight
75kg
Minimum Installation
w x d x h (and Door Swing)
826 x 762 x 793mm (520mm)
60L Benchtop Specifications
Working Volume
60 litres
Operating Range
up to 138°C, 2.4 bar
Loading Format
Front Loading
Loading Height
N/A
Heater Power
3kW – 13A single phase
Heat Input
Elements in Chamber
Chamber Size
diameter x depth
350mm dia x 625mm
External Dimensions
w x d x h
520 x 815 x 640mm
Bench Weight
85kg
Minimum Installation
w x d x h (and Door Swing)
826 x 968 x 793mm (520mm)
60L Benchtop Vacuum Specifications
Working Volume
60 litres
Operating Range
up to 138°C, 2.4 bar
Loading Format
Front Loading
Loading Height
Benchtop
Heater Power
3kW – 13A single phase
Heat Input
Heaters in Chamber
Chamber Size
diameter x depth
350mm dia x 420mm
External Dimensions
w x d x h
695 x 815 x 640mm
Bench Weight
85kg
Minimum Installation
w x d x h (and Door Swing)
826 x 968 x 793mm (520mm)
