Primus –
FS800 (80kg)
FS1000 (100kg)
FS1200 (120KG)
Freestanding, high spin
Stainless steel cabinet (AISI 304)
Stainless steel drum and tub
Xcontrol Plus – Fully programmable
microprocessor
Extra large door opening (FS800, FS1000
Ø 530 mm, FS1200 Ø 650 mm)
Two large drain valves (Ø 103 mm)
Easy access to all parts
Standard liquid soap connections
Frequency controlled motor
PowerWash® perforated lifting ribs:
more mechanical action, lower
water consumption
Air operated water inlet
SuperEco washing programmes
– signifi cantly reduces water and
electricity consumption
Patented soap dispenser with
5 removable compartments
HIGH SPIN INDUSTRIAL WASHER EXTRACTORS
FEATURES
■ Freestanding, high spin
■ Stainless steel cabinet (AISI 304)
■ Stainless steel drum and tub
■ Xcontrol Plus – Fully programmable
microprocessor
■ Extra large door opening (FS800, FS1000
Ø 530 mm, FS1200 Ø 650 mm)
■ Two large drain valves (Ø 103 mm)
■ Easy access to all parts
■ Standard liquid soap connections
■ Frequency controlled motor
■ PowerWash® perforated lifting ribs:
more mechanical action, lower
water consumption
■ Air operated water inlet
■ SuperEco washing programmes
– signi cantly reduces water and
electricity consumption
■ Patented soap dispenser with
5 removable compartments
OPTIONS
■ Liquid soap pumps
■ Trace-Tech® traceability software
and networking system
■ Forward and backward tilting is available.
Tilting of the machine is done
by external platform
LARGE DOOR
OPENING
ROBUST DESIGN EASY
OPERATION
FS
RANGE
The Primus preserves the right to change the machines and the specification in this leaflet at any time,
without prior notice. Details and photographs are only for information and never binding.
www.primuslaundry.com
Primus by Alliance Laundry Systems
TYPE FS800 FS1000 FS1200
CAPACITY
Drum volume l 807 1003 1180
Capacity kg/lb 80/180 100/230 120/275
Drum diameter mm Ø 1110 Ø 1200 Ø 1300
MOTOR
Frequency controlled standard standard standard
DRUM SPEED
Wash speed rpm 36 33 32
Spin speed rpm 750 720 695
G-Factor 350 350 350
PROGRAMMER
Xcontrol Plus
microprocessor standard standard standard
CABINET
Stainless steel AISI 304 standard standard standard
DRUM
Stainless steel AISI 304 standard standard standard
HEATING
Electrical kW 67,5 – –
Steam high pressure bar 3-8 3-8 3-8
psi 44-116 44-116 44-116
CONNECTION
Electrical 3×380-480V 50/60Hz
3×208-240V 50/60Hz
3×380-480V 50/60Hz
3×208-240V 50/60Hz
3×380-480V 50/60Hz
3×208-240V 50/60Hz
kW 11,25 15,25 18,75
Water inlet inch 3×1 1/2“ 3×1 1/2“ 3×1 1/2“
Steam inlet inch 1“ 1“ 1“
Compressed air inlet mm Ø 8 Ø 8 Ø 8
Drain mm 2×103 2×103 2×103
2×4“ 2×4“ 2×4“
DIMENSIONS
H×W×D mm 1985×1495×1940 2060×1790×2005 2085×1855×2085
Net weight kg 2640 3170 3480
TRANSPORT DATA
Volume (packed) m3 7,25 9,29 10,16
Packed H×W×D mm 2200x1690x1950 2345x1865x2125 2340x2000x2170
Gross weight kg 2830 3410 3710
