AP500 Wheel Asphalt Pavers

The Cat® AP500 Asphalt Paver is designed for urban streets, car parks, rural roads and many other small to intermediate-type applications. This paver provides high throughput capability as-well as application versatility, easy set-up, and a wide paving range. Paving Range with SE47 VT 2.4 m – 6.0 m (7′ 10″ – 19′ 8″) Engine Model (1) Cat C4.4 (U.S. Tier 4 Final, EU Stage V) Engine Power (1) 110 kW Product specifications for AP500 Wheel Asphalt Pavers The Cat® AP500 Asphalt Paver is designed for urban streets, car parks, rural roads and many other small to intermediate-type applications. This paver provides high throughput capability as-well as application versatility, easy set-up, and a wide paving range. Dimensions expand / collapse icon Paving Range with SE47 VT 2.4 m – 6.0 m (7′ 10″ – 19′ 8″) Paving Range with SE50 VT 2.55 m – 6.77 m (8′ 4″ – 22′ 3″) Truck Entry Height 537 mm Operating Length 5.9 m Operating Width 3.3 m Overall Height 3.9 m Transport Length 5.7 m Transport Width 2.5 m Transport Height 2.9 m Engine expand / collapse icon Engine Model (1) Cat C4.4 (U.S. Tier 4 Final, EU Stage V) Engine Power (1) 110 kW Engine Model (2) Cat C4.4 (UN ECE R96 Stage IIIA, equivalent to U.S. EPA Tier 3 and EU Stage IIIA) Engine Power (2) 106 kW Operating Specifications expand / collapse icon Maximum Travel Speed 16 km/h Maximum Paving Speed – With Tamper Bar Screed 25 m/min Maximum Throughput Capacity 1000 tonnes/hr Weights expand / collapse icon Operating weight with SE47 VT 15351 kg Operating weight with SE50 VT 15430 kg Shipping Weight – Paver Only 12026 kg Service Refill Capacities expand / collapse icon Fuel Tank 200 l DEF Tank 19 l Cooling System – Total 24 l Hydraulic Oil Tank 121 l Washdown Spray Tank 32 l More Performance and Flexibility Powerful C4.4 engine supports increased feeder system capacity as well as hopper inserts for continuous paving Tight 90º turning capability enables the paver to rotate and cover its tracks on a return paving pass Standard paving range utilizing the SE47 VT screed is 2.4 m – 4.7 m (7′ 10″ – 15′ 4″) with a maximum width of 6 m (19′ 8″) Standard paving range utilizing the the SE50 VT is 2.55 m – 5.0 m (8′ – 15′ 6″) with a maximum width of 6.77 m (22′ 3″) Paving depths up to 300 mm (12″) supports aggregate paving applications Transport Made Easy Machine weight of less than 14.5 mt (32,000 lb) paver and screed combination enables easy transport on a variety of trailer types Length of less than 5.7 m (18′ 9″) and width of 2.55 m (8′ 4″) when equipped with the SE47 VT accommodates machine transport without special permits Length of less than 6.0 m (19′ 6″) and width of 2.55 m (8′ 4″) when equipped with the SE50 VT and folding end gates accommodates machine transport without special permits The front-loading angle of 17º and high front bumper clearance reduces the need for additional blocking when loading onto various trailer designs Front, middle, and rear tie-down locations make securing the paver highly efficient for quick travel to the next job site Exceptional Mobility Wheel undercarriage provides exceptional mobility and fast travel speeds for unmatched maneuverability around the job site Excellent traction is delivered through the 17.5 R25 radial drive tires Front-wheel assist option provides power to the rear set of bogie wheels for excellent performance in tough conditions All-wheel drive option utilizes a flow divider to deliver power to both sets of front bogie wheels for additional pulling power High ground clearance of 197 mm (7.8″) helps avoid storm drains, curbs, and other obstacles Smooth Material Flow Optimized hopper design with low truck entry height and short front apron enhances material flow while simplifying clean-out Enhanced feeder system with 355 mm (14″) diameter augers provides consistent material flow across the screed for efficient flow at both narrow and wide paving widths Confined auger chamber keeps material moving and helps eliminate stagnate patches Independent control of each material feed sensor when utilizing a cut-off shoe, simply turn off the sensor for manual proportional feed control More Comfort Optional ventilation system draws fumes from the auger chamber and redirects them away from the operator for a more comfortable working environment The single sliding console provides operation from either side of the machine for optimal visibility to curbs, edges, and transverse joints Dual independent seats swing out 40º beyond the platform for good visibility to curbs and obstacles Optimized height and integrated exhaust provide unobstructed visibility around the machine Optional screed and paver mounted umbrellas offer protection from direct sunlight Heated seat option delivers comfort in cool weather High visibility 76 mm (3″) seat belt assists with crew safety compliance Easy Viewing Displays High-definition, touchscreen displays with adjustable brightness control for all types of lighting conditions, including direct sunlight High-visibility touch screen operating display with simplified menu structures, intuitive graphics, and short-cut keys help simplify machine adjustments Single-touch functions from main screen include screed heat, washdown system, vibratory activation, ventilation system, accessory panel Cat® Grade Control or Basic Grade Control options available Operating displays can be tailored to specific language requirements with multiple options available Wash-down system includes level indication Low Owning and Operating Costs Durable Cat C4.4 engine provides 110 kW (148 hp) of power with variations that meet U.S. EPA Tier 4 Final and EU Stage V emission standards. The Cat C4.4 engine also meets Brazil MAR-1 and UN ECE R96 Stage IIIA emission standards, equivalent to U.S. EPA Tier 3 and EU Stage IIIA and provides 106 kW (142 hp) of power. Single source supplier of Cat engines and machine parts helps maximize uptime Exclusive Eco-mode and Automatic Engine Speed Control reduce fuel consumption and lower sound levels for better comfort and communication Conveyor bed plates and chain guards designed to minimize labor requirements and provide lower cost replacement Maintenance-free high torque motors reduce service requirements for the auger and conveyor drive systems Product Link™ Elite Make timely, fact-based decisions to maximize efficiency, improve productivity, and lower owning and operating costs Easily track location, machine hours, fuel usage, and idle time in real time Diagnostic codes are made available through online web applications Remote flash for easy software updates Scheduled maintenance and Scheduled Oil Sampling notifications Remote disable deactivates the engine for enhanced security Service and Repair Kits Paver and screed service and repair kits include all the parts necessary to complete specific repairs Cat genuine parts are manufactured to precise specifications and designed for optimal performane and maximum uptime Repair kits are identified by a single part number to make ordering easy Select kits are available to be packaged as a kit by the dealer for over the counter purchases or through the dealer service shop AP500 Standard Equipment Expand all Operating Environment expand / collapse icon Single sliding console Steering guide Technology expand / collapse icon Product Link™ Elite 643 (cellular) Powertrain expand / collapse icon Cat® C4.4, four-cylinder Cooling fan, variable speed Radial drive tires Electrical System expand / collapse icon 1400 CCA battery, maintenance-free 150-amp alternator 12-volt charging system Automotive-type fuse system Auto-reset breaker for material sensors Cat® Electronic Technician (Cat ET) Material Delivery expand / collapse icon Auger extensions, 0.15 m (6″) Material feed sensors, contact Push-roller, adjustable Service and Maintenance expand / collapse icon Hydraulic oil, Cat HYDO™ Advanced Remote access drains Remote flash Service repair kits Sampling ports for Scheduled Oil Sampling Sight Gauges, engine coolant, hydraulic oil Safety expand / collapse icon Alarm, back-up Horn, warning (front & rear) Lights, LED Working Mirror package AP500 Optional Equipment Expand all Operating Environment expand / collapse icon Canopy, hydraulic lift, manual Canopy, hydraulic lift, power Deceleration pedal Dual operating consoles Heated seat Side Shields Umbrella Ventilation system Windshield Technology expand / collapse icon Cat® Grade Control Basic Grade Control Product Link™ Elite 683 Cellular/Satellite Powertrain expand / collapse icon All-wheel drive Ballast – front weights Front-wheel assist Material Delivery expand / collapse icon Auger extensions, 0.46 m (1.5′) Mainframe extensions, power Mainframe extensions, manual Material feed sensors, sonic Tamper Bar System Wash-down pump and reel Tamper Bar System Safety expand / collapse icon Lights, LED Roading Warning beacon, LED
