Easy chip flow splash guard design.
High speed linear guide used on 3-axes of machine, accomplish super load capacity and rigidity.
The enhanced ribs in major construction parts provide the super rigidity for heavy duty cutting or for high speed cutting.
The heavy-duty linear guide way is applied in X, Y, and Z axes. It is free from loads deformation. High speed feed-rate and repeatability accuracy are guaranteed.
X/Y/Z Linear guide ways.
(Spec.:)
kw 1.8/1.8/2.5
X-Y-Z motor(Mitsubishi) kw 1.5/1.5/3
X-Y-Z Rapid travel m/min 48/48/36 4
X-Y-Z Cutting feed rate m/min 10
ATC System
ATC type. Arm type
Magazine capacity pcs 24T
Max.tool diameter Ø(mm) Ø80
Max.tool length mm 200
Max.tool weight kgs 7
Rail Type
Rail Type – 3-axes Linearways
Dimensions&others
Power consumption KVA 15
Air pressure required kfg/CM² 6
Floor occupation cm 220×285
Machine weights kg 4300
**Buyers with interest reach out to me at Email: [email protected] for more details and for shipping and payment terms.
Shipping overseas available.
