The versatile Cat® D4 dozer offers the power and precision to get jobs done quickly, plus gives you up to 30 percent more visibility in front of the blade. Easy-to-use technology features help you get more quality work done in less time. Fuel efficiency and service improvements help reduce your operating costs.
Engine Model
Cat C4.4
Power – Net
97 kW
Net Power – ISO 9249
97 kW
Product specifications for D4 Medium Dozers
Engine
expand / collapse icon
Engine Model
Cat C4.4
Power – Net
97 kW
Net Power – ISO 9249
97 kW
Net Power – ISO 9249 (DIN)
132 mhp
Emissions
U.S. EPA Tier 4 Final/EU Stage V/Japan 2014/Korea Stage V
Note (1)
Net power available at the flywheel when the engine is equipped with fan, air cleaner, aftertreatment, and alternator with engine speed at 2100 rpm. Advertised power is tested per the specified standard in effect at the time of manufacture.
Note (2)
Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels** up to: 20% biodiesel FAME (fatty acid methyl ester) * or 100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels. Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details. * Engines with no aftertreatment devices can use higher blends, up to 100% biodiesel (for use of blends higher than 20% biodiesel, consult your Cat dealer). ** Lower-carbon intensity fuels do not significantly reduce GHGs at the tailpipe.
Note (3)
Machine Build Number 16B
Weights
expand / collapse icon
Operating Weight
13272 kg
Transmission
expand / collapse icon
Power Train
Hydrostatic Transmission
Service Refill Capacities
expand / collapse icon
Fuel Tank
260 l
DEF Tank
19 l
D4
expand / collapse icon
Operating Weight
13272 kg
Ground Pressure
40.5 kPa
Width of Standard Shoe
560 mm
Blade
VPAT or VPAT Foldable*
Blade Capacity
3.26 m³
D4 LGP
expand / collapse icon
Operating Weight
14008 kg
Ground Pressure
31 kPa
Width of Standard Shoe
760 mm
Blade
VPAT or VPAT Foldable*
Blade Capacity
3.81 m³
Blades
expand / collapse icon
Note
*VPAT foldable blades have the same capacity and width as the XL/LGP VPAT blades.
Sustainability
expand / collapse icon
Recyclability
93%
Air Conditioning System
expand / collapse icon
Air Conditioning
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.6 kg of refrigerant which has a CO2 equivalent of 2.288 metric tonnes.
BIG PERFORMANCE, BETTER VIEW
Get a better view of the work at hand with a lower sloping hood line that gives you up to 30 percent better visibility to the area in front of the blade.
Superior maneuverabilty, fast steering response give you the agility to get the job done quickly.
The undercarriage design, with eight bottom rollers and two carrier rollers, is optimized for smooth finish grading and a better ride, even at faster grading speeds.
Cat C4.4 engine with twin turbochargers combined with a hydrostatic transmission to give you excellent fuel efficiency and the most power-dense drive train in its size class.
All comparisons to D6K2/previous model D4 without Cat Technology
EASY ON OPERATORS
Updated cab offers more comfort and convenience for long days in the seat.
Easy-to-use 10 in (254 mm) touchscreen main display is common across the latest models in the Cat dozer lineup.
Standard High Definition rearview camera shows prominently in the main display.
More comfortable seat offers improved suspension and multiple adjustments for personalized comfort.
Bi-directional control lets you preselect forward/reverse gears for reduced effort and to match your application. Save the settings as operator profile for even more convenience.
Additional storage spaces throughout the cab.
USB jack and additional 12V ports for added convenience.
Larger step on the C-frame aids access/egress.
Comparisons to D6K2/previous model D4.
OPERATOR HELPERS
Assist features help make work easier, especially for less experienced operators. Some blade and steering functions are automated so newer operators can work at productivity levels closer to their veteran counterparts. Seasoned operators can enjoy reduced effort and fatigue, along with faster, more accurate results.
The ARO with Assist package is now STANDARD on D4 dozers.
Cat Grade with Slope Assist™ automatically maintains pre-established blade position without a GNSS/GPS signal – no additional hardware or software needed. For machines with 3D, operators can easily switch back and forth from full 3D automatics to Slope Assist.
Steer Assist** automates track and blade tilt steering. Helps reduce operator fatigue by automatically maintaining straight travel with light loads or heavy loads on flat ground and side slopes. Helps reduce steering inputs up to 75%. No GNSS/GPS required.
Stable Blade works seamlessly with operator inputs to help produce a smoother surface when operating manually.
Blade Load Monitor gives you real-time feedback on current load versus the optimal blade load based on your ground conditions. Actively monitors machine load and track slip to help you reach optimal pushing capacity.*
Traction Control automatically reduces track slip to save you time, fuel and track wear.*
AutoCarry automates blade lift to help you maintain consistent blade load and reduce track slip.*
Slope Indicate is included in the main machine display and shows side slope and uphill/downhill grades to help operators with slope work.
Attachment Ready Option (ARO) provides wiring and mounting provisions for dealer installation of Grade with 3D, Accugrade, UTS, or other grade control systems.
*Feature not operational indoors or in areas where a GNSS/GPS signal is not available.
** Available early 2024
TOP GRADES
Factory integrated Cat Grade with 3D uses GNSS/GPS to control the blade so you can get to design plan faster.
Cat Grade with 3D has no masts – low profile antennas are integrated into the cab roof and GNSS/GPS receivers are mounted inside the cab for better protection.
Automatically follow guidance lines from design plans with Steer Assist 3D.* Stay on curb lines, centerlines, bottom of slope, etc., without operator effort. Track steering is used under light loads and blade tilt steering may be added under heavy loads.
Grade operator interface is intuitive and easier to use: 10-inch (254 mm) touchscreen, Android OS platform, operates like a smart phone.
All Cat Grade systems are compatible with radios and base stations from Trimble, Topcon, and Leica.
Already invested in a grade infrastructure? You can install grade systems from Trimble, Topcon, and Leica onto the machine.
The cab is Third Party Grade Control Ready, equipped with CAN interface, harness pass throughs and mounting features to make it easier to install the grade control system of your choice.
*Available early 2024
PROVEN ADVANTAGE
Cat Assist and Grade technologies work in the background to help dozer operators of varied skill levels and are especially beneficial to less experienced operators. To demonstrate just how much these built-in technology features help, Caterpillar put them to the test. Two novice operators and two expert operators took on slot dozing, truck dump spreading/grading in sand, and side slope work. Each operator completed three runs of each task – one in manual, one using Assist technology features, and one using Assist plus Cat Grade with 3D. The team measured productivity*, efficiency**, completion time, final surface quality, and operator inputs.
Slot Dozing
Productivity and Efficiency – Novice operators went from 9% lower productivity and efficiency than the experts in manual to matching the experts when using Assist.
Truck Dump Spreading/Grading in Sand
Completion Time – Novice operators took 49% more time than the experts in manual and narrowed the gap to 17% using Assist and to 9% by adding Grade.
Blade Inputs – Novice operator blade inputs were reduced 45% with Assist, and 55% with Assist plus Grade. Expert operator blade inputs were reduced 32% with Assist, and 53% with Assist plus Grade.
Surface Quality – Novice operator surface quality improved up to 51% using technology while expert operator surface quality improved up to 27% using technology. Novice operators using technology produced similar surface quality to the expert operators in manual.
Side Slope/Steer Assist
Steering Inputs – Novice and expert operator steering inputs reduced by 75% in forward and by 67% combining forward and reverse.
*Material moved per hour
**Material moved per unit of fuel/Diesel Exhaust Fluid (DEF)
Study conducted by Caterpillar, August 2022
CONNECT TO GREATER EFFICIENCY
Product Link collects machine data that can be viewed online through web and mobile applications.
Access information anytime, anywhere with VisionLink® – and use it to make informed decisions that boost productivity, lower costs, simplify maintenance, and improve safety and security on your job site.
The Cat App helps you manage your assets – at any time – right from your smartphone. See fleet location and hours, get critical required maintenance alerts, and even request service from your local Cat dealer.
Remote Troubleshoot saves time and money by allowing your Cat dealer to perform diagnostic testing remotely.
Remote Flash updates on-board software without a technician being present, at a time that is convenient for you, potentially reducing update time by as much as 50 percent.
OPERATING COST SAVERS
Eco modes optimize engine speed, while maintaining ground speed and power, to save you fuel in lighter blade load applications like finish grading.
Efficiency features reduce engine speed when idling, or shut the machine down after a specified time, to further save fuel and meet idling regulations.
Efficient cooling package has better air flow, helping to reduce fan speed and save even more fuel in cooler conditions/lighter applications.
Cat Abrasion™ undercarriage is your lowest cost-per-hour solution for high abrasion and low impact jobsites. The design offers double the seal life and eliminates bushing turns, reducing your costs up to 50 percent per hour compared to traditional undercarriage.
Cat Precision Cutting Edges protect your blade investment with 20% more wear material and lower cost per hour, plus 40% more wear material on extended wear life edges.* Cat Precision Cutting Edges are the only ones with wear indicators rolled right into the edge material, to ensure you know when to flip your cutting edges to avoid costly blade repairs.
*Compared to legacy cutting edges. (Available early 2024)
BECAUSE UPTIME COUNTS
Engine oil/engine oil filter service interval has been extended to 1,000 hours*.
Updated fuel system and more than three-times longer DEF filter service interval.
LED lights offer up to six times the life of halogen.
Larger engine compartment door for easier access to service and maintenance points.
Remove lower service panel without tools for quick access to inspect engine compartment and filters.
Ground level access to hydraulic filters and primary fuel filter/water separator.
Optional bracket mounts to rear of machine to keep a shovel handy.
Monitoring system with automatic checks at start up.
Trunnion grease point can now be reached without bending down.
Optional ground level fast fuel fill.
Longer drawbar platform for more convenient fuel fill/rear camera cleaning.
All comparisons to D6K2/previous model D4.
*First change at 500 hours. Scheduled Oil Sampling (S·O·SSM) required. Please refer to Operation and Maintenance Manual (OMM) for details.
SUSTAINABILITY
The Cat C4.4 engine meets U.S. EPA Tier 4 Final, EU Stage V, Japan 2014, and Korea Stage V emission standards.
The D4 emits up to 5% less CO2 than the previous D6K2*.
Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels up to: 20% biodiesel FAME (fatty acid methyl ester) ** or 100% renewable diesel, HVO (hydrogenated vegetable oil) and GTL (gas-to-liquid) fuels. Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details.
Auto Engine Speed Control helps reduce unnecessary fuel burn and greenhouse gas emissions by allowing the engine to automatically go into idle mode when the machine is not working.
AutoCarry automates blade lift to reduce track slip for maximum efficiency on each pass to help lower fuel burn and greenhouse gas emissions.
Cat Grade with Slope Assist helps you avoid costly rework and wasteful fuel burn and greenhouse gas emissions by automating your blade position without a GPS signal.
Cat Grade with 3D automates blade movements using a GPS signal helping you follow a grade design, reducing fuel burn and greenhouse gas emissions by improving efficiency and accuracy.
Extended maintenance intervals not only reduce downtime but decrease the amount of fluid and filters that are replaced over the life of the machine.
VisionLink displays the CO2 emissions for monitored assets, calculated by fuel type for the Runtime Fuel Burned each day in a selected date range.
Remote Flash minimizes downtime and maintenance time while keeping your asset running with maximum efficiency. Alerts for machine updates are sent virtually from your Cat dealer and updates can be deployed without a dealer technician needing to be onsite.
Remote Troubleshoot decreases maintenance time and keeps your machine running with maximum efficiency by allowing your Cat dealer to virtually test the machine while working. Once a problem is identified, a technician can fix it the first time, saving time and money.
*All comparisons to D6K2. Productivity, fuel and CO2 emissions vary by application. CO2 emissions calculations based on a reference work cycle using 2.2 U.S. gallons per hour of #2 U.S. diesel fuel based. Applies IPCC2006 methodology using U.S. EPA Emissions Hub emission factors. Includes DEF (diesel exhaust fluid) related CO2. Fuel measurements are at 15°C. Estimated average fuel consumption improvements are based on tests or Product Link® data where available. Productivity improvements are based on test data.
**Engines with no aftertreatment devices can use higher blends, up to 100% biodiesel.
D4 Standard Equipment
Expand all
NOTE
expand / collapse icon
Standard and optional equipment may vary. Consult your Cat dealer for details.
Power Train
expand / collapse icon
Cat C4.4 diesel engine
Air cleaner with integrated pre-cleaner, dust ejector and under hood air intake
Air-to-air aftercooling
Aluminum bar plate cooling system
Auto engine speed control
Electric fuel pump
Engine idle shutdown
Hydraulically driven, variable speed fan
Hydrostatic, infinitely variable speed transmission
Operator Environment
expand / collapse icon
Standard ROPS/FOPS cab
Integrated air conditioning
Air-suspension cloth seat
Adjustable armrests
10-in (254 mm) touch screen display
Rear vision camera
Electronically programmable speed selector
Programmable/selectable Bi-Directional shifting
Electronic engine air cleaner service indicator
12 V power port
Entertainment Radio ready
Cat Technology
expand / collapse icon
Slope Indicate
ARO with Assist Package: Includes Attachment Ready Option (ARO), Slope Assist, Steer Assist*, Stable Blade, Blade Load Monitor, Traction Control, AutoCarry
Product Link, Cellular
Remote Flash/Troubleshoot
Operator ID
Machine Security – Passcode
Compatibility with radios and base stations from Trimble, Topcon, and Leica
Capability to install 3D grade systems from Trimble, Topcon, and Leica
Undercarriage
expand / collapse icon
Heavy Duty undercarriage
Cat Abrasion undercarriage
Lifetime lubricated track rollers (8 + 2 carrier rollers) and idlers
Tracks 40 sections -560 mm (22 in) Moderate Service – Standard
Tracks 40 sections -760 mm (30 in) Moderate Service – LGP
Electrical
expand / collapse icon
105 Amp brush-type alternator (24 volt)
Backup alarm
Diagnostic connector
Integrated halogen lights – 4 front, 2 rear
Hydraulics
expand / collapse icon
Three valve-hydraulics
Load sensing hydraulics
Service and Maintenance
expand / collapse icon
Extended service intervals
Ecology drains (engine oil, engine coolant, hydraulic)
Blades
expand / collapse icon
VPAT blade
Manual blade pitch
Precision Cutting Edges*
Attachments
expand / collapse icon
Front pull device
*Available early 2024
expand / collapse icon
D4 Optional Equipment
Expand all
NOTE
expand / collapse icon
Standard and optional equipment may vary. Consult your Cat dealer for details.
Power Train
expand / collapse icon
Precleaner with turbine
Auto reversing fan
Operator Environment
expand / collapse icon
Comfort cab package
Heavy duty cab package
Radio, AM/FM/AUX/USB Bluetooth
Cat Technology
expand / collapse icon
Grade 3D with Assist Package: Includes full-color 10-inch (254 mm) touchscreen grade display, Steer Assist 3D*, Grade receivers and antennas, Grade Software Enabled Attachment (SEA), ARO with Assist package features
Product Link, Dual Cellular/Satellite
Machine Security – Bluetooth
Electrical
expand / collapse icon
6 LED lights
8 LED lights – premium
Undercarriage
expand / collapse icon
Moderate service or Extreme Service track shoes
Track guiding guards – full, center, front/rear
Service and Maintenance
expand / collapse icon
Fast fill ready
Bio hydraulic oil
Cold weather package (120V or 240V)
Engine coolant heater (240V)
Shovel mounting bracket
Fuel refilling pump
High speed oil change
Blades
expand / collapse icon
Folding VPAT blade
Power blade pitch
VPAT blade
Attachments
expand / collapse icon
Ripper Ready package
Winch ready
Dual Ripper/Winch Ready package
Winch (dealer installed)
Ripper with curved or straight shanks
Drawbar
Rear counterweight
Protection packages – standard, front or heavy duty guarding
Rear screen
*Available early 2024
