CANADIAN SOLAR 430W TOPHIKU6 MONO ALL BLACK MC4 SOLAR PANEL
Thinking of installing a solar panel in your home, farm, or garden office? Look no further. These solar panels are reliable, efficient, and cost-effective with an attractive payback period. Well-designed in a durable black frame, these panels are suitable for domestic, farm, garden office, and similar rooftop installations.
The Canadian Solar 430W TOPHiKu6 Mono All Black MC4 (CS6R-420|425|430|435|440T) solar panel is a 430W monocrystalline module with proprietary mono wafer and cell technologies. Canadian Solar offers a high-efficiency module with N-type TOPCon cells, providing high power output, a better temperature coefficient, lower efficiency loss against shading, and higher resistance to mechanical loads. With excellent anti-LeTID and anti-PID, it also comes with a 12-year product warranty and 25-year linear power output warranty.
Ideal for residential rooftop applications, these panels stand out for their incredible quality/price ratio and their great power in a small size.
Features:
SUPER HIGH EFFICIENCY MODULE: 430W output in adequate light conditions. Actual output will vary with factors such as elevation, weather, temperature, time of year, angle, and position in relation to the sun.
UPGRADE FOR MORE POWER: A special feature designed for these panels allows connecting multiple panels with parallel cables, increasing power produced for your Solar Power Generator.
DURABLE, DUST & WATER RESISTANT: The solar panel is dust and water-resistant and is designed to withstand all weather conditions. The anti-reflective and anti-soiling surface reduces power loss from dirt and dust.
MORE RELIABLE:
Lower internal current, lower hot spot temperature
Cell crack risk limited to a smaller area of the cell
Innovative symmetrical module design means better shading tolerance
Heavy snow load up to 5400Pa and increased wind load up to 3600Pa
SUPERIOR WARRANTY: 12-year product warranty and 25-year extra linear power output warranty.
Must be installed by a licensed technician or electrician.
In the Box:
Canadian Solar 430W Solar Panel
Canadian Solar 430W Solar Panel Installation Manual
Delivery:
TWO WORKING DAY SHIPPING if ordered by 5 PM on a working day (longer to the Scottish Highlands, Islands, and Northern Ireland).
Detailed specifications:
Rated (Peak) Power (Wp): 430W in Standard 1000w/m2 solar light
Open Circuit Voltage (Voc): 39.0V (Vmp =32.0V)
Short Circuit Current: 13.86A (Imp = 13.44A)
Efficiency: 22.0%
Cell Type: Monocrystalline Silicon
Connector Type: MC4
Certification: IEC 61215 / IEC 61730 / CE / INMETRO / MCS / UKCA
Net Weight: 21.3 KG
Size: 1722 X 1134 X 30mm
Gap Between Mounting Holes: 1093mm
FREQUENTLY ASKED QUESTIONS
WHAT IS CANADIAN SOLAR COMPANY?
Canadian Solar stands as one of the global leaders in solar panel production, having pioneered innovative technologies for high-performing solar modules.
The company, established in 2001 by Chinese engineer Dr. Shawn Qu, operates as a Canadian company, registered and headquartered in Canada (Guelph, Ontario), despite its strong ties to China.
SINCE WHEN HAS CANADIAN SOLAR BEEN A PUBLICLY-TRADED COMPANY?
Canadian Solar has been publicly traded since November 2006, listed on the Nasdaq Stock Market.
HOW HAS CANADIAN SOLAR GROWN SINCE ITS INCEPTION IN 2001?
Since its establishment in 2001, Canadian Solar has experienced remarkable growth, evolving into the world’s fifth-largest producer of solar panels. As of 2021, the company has shipped approximately 63 GW of solar modules.
WHERE ARE CANADIAN SOLAR PRODUCTS MANUFACTURED?
Canadian Solar operates 20 manufacturing facilities across Asia and the Americas. Although the company’s first production took place in China in 2002, it has expanded its manufacturing presence to various locations, with the largest manufacturing plant situated in Suzhou, China.
ARE CANADIAN PANELS TIER 1 QUALITY?
Yes, Canadian Solar products boast Tier 1 quality. Leveraging advanced technology, the company delivers highly efficient and durable solar panels.
WHAT ARE THE TECHNOLOGICAL ADVANCEMENTS IN CANADIAN SOLAR MODULES?
Canadian Solar incorporates cutting-edge technologies in its modules, including:
Dual Cell technology: Allows a panel to work as two parallel modules with independent performance, providing better shade tolerance.
Multi Busbar technology: Increases the pathway for electricity within solar cells, reducing electrical resistance.
PERC technology: Involves adding a dielectric passivation layer to enhance light capture and energy conversion efficiency.
LIC panels: Feature lower internal current, reducing hotspot temperature and minimizing the risk of cell cracking and damage.
HAS CANADIAN SOLAR SET ANY WORLD RECORDS?
Yes, Canadian Solar holds solar world records. In March 2020, it set a world record of 23.81% conversion efficiency for an n-type multi-crystalline P5 solar cell. Additionally, the company achieved a previous record of 22.8% efficiency in September 2019.
SINCE WHEN HAS CANADIAN SOLAR BEEN RATED A TIER 1 SOLAR COMPANY?
Since 2017, Canadian Solar has held the prestigious Tier 1 rating by Bloomberg New Energy, signifying the reliability and bankability of its products.
WHAT ARE CANADIAN SOLAR HIKU PANELS?
Canadian Solar HiKu panels are High Power Dual Cell PERC Solar Modules, available in both monocrystalline and polycrystalline configurations. Renowned as one of the most popular panels, the HiKu is ideal for residential PV systems, offering 30% more power than conventional panels. It features dual cell technology for enhanced shade tolerance and reduced losses, along with an industry-high warranty of 25 years.
HIKU OVERVIEW:
Power range: 330 – 550 W
Efficiency: 20.5% to 21.5%
Lower hotspot temperature
LID and LeTID: less than 2%
