EXPERIENCE UNINTERRUPTED POWER WITH SOLIS 5.0KW 3-PHASE HYBRID ON-GRID/OFF-GRID INVERTER
Unleash the potential of your solar energy system with the Solis 5.0kW 3-Phase RHI-3P5K-HVES-5G Hybrid On-grid/Off-grid 5G Inverter, providing essential power during load shedding and optimising energy usage during peak demand.
Key Features:
Max. efficiency 98.4%
Intelligent EMS function
Support three-phase imbalance on backup output port
2 MPPT and 4 DC input; Max 13A DC input current
Time of use shifting and peak shaving capabilities to grid
AFCI protection, proactively reduces fire risk
Remotely control and upgrade any selected inverter
Power supply can be switched automatically and switching time within 40ms
Ensures AC backup for up to 5kW of continuous power and 10kVA of peak power
24-hour fully intelligent energy management, Real-time display of PV plant status
Remotely controlled upgrade function
Four Work Modes:
Self-consumption mode: Prioritises using energy produced by the PV system for self-consumption. Excess energy charges the batteries and is then exported to the grid.
Feed-in priority: Utilises power generated by the PV system to supply local loads first, exporting excess power to the grid. Redundant power charges the battery.
Back-up Mode: Maintains the battery at a specific State of Charge (SOC) and only utilises it during power outages.
Off-Grid Mode: For off-grid use and AC-Grid Port Disconnected use.
Battery Compatibility: The Solis RHI-3P5K-HVES-5G 5.0kW 3-Phase Hybrid On-grid/Off-grid 5G Inverter seamlessly integrates with LG RESU10H PRIME and LG RESU16H PRIME High Voltage Batteries.
Fast Delivery Across the UK: Experience quick 2-3 working days delivery within the UK (longer to the Highlands, islands, and Northern Ireland). Elevate your power resilience with the Solis 5.0kW 3-Phase Hybrid On-grid/Off-grid 5G Inverter.
Detailed specifications:
Model: RHI-3P5K-HVES-5G
BATTERY
Battery Type: Lithium-Ion
Battery Voltage: 160-600V
Max. Charge/Discharge Power: 5000W
Max. Charge/Discharge Current: 25A
Max. Charge/Discharge Power: 5kW
Communication Interface: CAN/RS485
INPUT PV
Max. Input Power: 8000W
Max. Input Voltage: 1000V
Start-up Voltage: 120V
Rated Voltage: 600V
MPPT Operating Voltage Range: 200-850V
Max. Input Current: 13A/13A
Max. Short-circuit Current: 19.5A/19.5A
No. of Independent MPP Trackers/Max. input strings number: 2/2
OUTPUT AC (GRID SIDE)
Rated Output Power: 5000W
Max. Output Apparent Power: 5000VA
Rated Grid Output Current: 7.6A / 7.2A
Max. Output Current: 8A
Rated Grid Voltage: 3/N/PE, 380/400V
Rated Grid Frequency: 50/60Hz
Power Factor: >0.99 ( Adjustable from 0.8 leading to 0.8 lagging )
THDi: <2% @rated power
OUTPUT AC (BACK-UP)
Rated Output Power: 5000W
Max. Output Apparent Power: 5000VA
Peak Output Apparent Power: 10,000VA@60sec
Rated Output Current: 7.6A / 7.2A
Max. Output Current: 8.4A
Rated Output Voltage: 3/N/PE, 380/400V
Rated Output Frequency: 50/60Hz
THDi (linear load): <2%
Backup Switch Time: <40ms
EFFICIENCY
Max. Efficiency: 98.4%
Operating Temperature: -25 ~ +60°C
Protection Degree: IP65
Size: 535*455*181mm
Net Weight: 25.1kg
In the Box:
1 X Solis RHI-3P5K-HVES-5G 5.0kW Hybrid On-grid/Off-grid 5G Inverter,
1 X Solis RHI-3P5K-HVES-5GL 5.0kW Hybrid On-grid/Off-grid 5G Inverter User's Manual.
